Slant Bed

Bed incline

°

30

Max. workpiece length

mm

960

Cutting capacity over bed

mm

￠400

Chuck size

A2-10

Spindle power

KW

11

Spindle speeds

rpm

3500

Spindle bore

mm

￠83

Dia.of bar through spindle bore

mm

￠75

Rapid feed speed

m/min

18

X Axis Travel

mm

230

Z Axis Travel

mm

1000

Tailstock sleeve diameter

mm

￠65

Tailstock sleeve travel

mm

100

Tailstock travel

mm

780

Tailstock taper

MT4

Positioning accuracy

mm

±0.008(X) ±0.011(Z)

Repeatability accuracy

mm

±0.008(X) ±0.011(Z)

Overall dimension

mm

4500x1750x2000

Weight

T

3.8/4.2
