Slant Bed

Bed way angle

45°

Guide way type

Linear way

Max. dia. swing over bed

Φ580

Max. turning dia. over bed

Φ580

Max. turning dia. over turret

Φ360

Max. turning length

1000

Distance between centers

1320

Chuck model

A2-8

Chuck size

10”

Main motor

15KW

Max. spindle speed

2600rpm

Spindle bore

Φ87

Bar through spindle bore

Φ72

X-axis ballscrew model

GQ4006-C3

X-travel

350

Z-axis ballscrew model

GQ5010-C4

Z-travel

1120

X、Z connection type

Direction

Turret –hydraulic

10/12-position

Tool size

25X25

Dia. of tailstock quill

Φ100

Tailstock quill travel

120

Tailstock travel

1250

Tailstock taper

MT5

Oversize

4580×1880×2000

Weight

6800Kg
